Surge / High Voltage Protection using Metal Oxide Varistor (MOV)

There are times when power Supply in your surges and all devices goes for a Toss.

Fuse prevents the devices from High current but not from High Voltage ,To prevent devices burning up due to high voltage a simple device called a “Metal Oxide varisitor”

(MOV) can be used.

Put MOV in parallel to Power supply to each Device after Fuse to protect over voltage

varistor 07D Series (Should cost around Rs2 /Rs 5 INDIA)

Part Number

Varistor  Voltage

Maximum Allowable Voltage

Clamping Voltage(Max)

Maximum Energy

Maximum

Peak Current

Rated Power

Typical Capacitance (Reference)

(8/20μS)

(10/1000μS)

( 8/20μS )

Standard

High Surge

V1mA

ACrms

DC

Vc

Ip

Standard

High Surge

Standard

High Surge

(W)

(v)

(v)

(v)

(v)

(A)

(JOULE)

(A)

1kHz( pF)

07D361K

J

360(324-396)

230

300

595

10

25.00

32

1200

1750

0.25

140

07D391K

J

390(351-429)

250

320

650

10

25.00

35

1200

1750

0.25

130

07D431K

J

430(387-473)

275

350

710

10

28.00

40

1200

1750

0.25

115

07D471K

J

470(423-517)

300

385

775

10

30.00

42

1200

1750

0.25

105

07D511K

J

510(459-561)

320

415

845

10

30.00

45

1200

1750

0.25

100

07D561K

J

560(504-616)

350

460

925

10

30.00

49

1200

1750

0.25

90

07D621K

J

620(558-682)

385

505

1025

10

33.00

55

1200

1750

0.25

80

clip_image002

clip_image003

Typical MOV application. The MOV is connected in shunt across the power source, behind the fuse.

clip_image004
